Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling

Foton Auman 10m3 12m3 14m3 Capacity Compacted Garbage Truck, 10 Ton 12-ton Compactor Garbage Truck, Factory Direct Selling. We are the manufacturer.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
FYBJ5165
Transmission Type
Manual
Payload
12ton
Fuel
Diesel
Drive Wheel
4×2
Brand
FOTON
Models
Medium
Usage
Compression Type
Condition
New
Truck Model
12m3 Compactor Garbage Truck
Engine Model
Yc6j200-42
Horsepower
200HP
Transmission
Mld, 6 Gears Frowards and 1 Reverse.
Tyre
8.25-20-14pr Nylon Tire
Max Speed
85km/H
Operation
PLC Automatic Operation, with Manual Operation
Delivery
Within 40 Days
Transport Package
Roro, Bulk Vessel or Frame Container
Specification
FOTON AUMAN 12M3 Compactor Garbage Truck
Trademark
FUYA
Origin
China
HS Code
8704223000
Production Capacity
200units Per Month

Product Description

HUBEI FUYA VEHICLE CO.,LTD

I. Details of FOTON AUMAN 10m3 12m3 14m3 capacity Compressed Garbage Truck 10 Ton 12Ton Compactor Garbage Truck Factory Directly Selling

(1) Functions:

Garbage compactor (also called waste compactor truck, garbage compactor truck, trash compactor, refuse collection truck, compactor garbage truck,
rubbish truck, bin wagon, dustcart, bin lorry, waste collection vehicle) is designed to collect and transport municipal solid waste.


Garbage compactor is composed of hermitical garbage box, hydraulic system and operating system, which could apply pressure to the waste to break down
bulky items, to load and transport more garbage by one time. Dirty liquid flows into waste sink, perfectly preventing repollution. When arriving at destination,
the garbage can be dumped completely. It is ideal solution for solid waste collection.


The operation system could be manual or electrical control.


Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling
II. FOTON AUMAN 10m3 12m3 14m3 capacity Compressed Garbage Truck 10 Ton 12Ton Compactor Garbage Truck Factory Directly Selling


Chassis Description

Product model

BJ5165ZYS-1

Brand

FOTON

Drive form

4x2

Type

Refuse Compactor Garbage Truck

Chassis model

BJ1165VHPHA-1

Overall dimension(mm)

7660x2500x3095

G.V.W(kg)

15800

Load capacity(kg)

5305

Curb weight(kg)

10300

Axle load(kg)

5800/10000

Axle number

2

Wheelbase(mm)

3800

Tyre size & quantity

9.00R20,10.00R20 & 6+1

F/R Overhang(mm)

1445/2415

Approach/Departure angle(°)

29/12

Front tread(mm)

1958

Rear tread(mm)

1864

Spring plate

10/12+9,8/10+8

Cab

One and half row

Engine Description

Engine model

YC6J200-42

Displacement(ml)

6500

Max. power(kw)

147

Net power(kw)

138

Horsepower(hp)

200

Max. speed(km/h)

90

Type of fuel

Diesel

Emission standard

EURO 4


(1) More than 12 years professional manufacturer experience.
(2) CCC ISO9001 agreement
(3) Be designed according to your requirements
(4) Small order can be accepted
(5) We accept 100% inspection, welcome to our factory at any time
(6) 12 month quality guarantee term

We can offer 4x2, 6x4, 8x4, Dongfeng, Sinotruck, FOTON, SHACAN, FAW, CAMC, I SUZU, JMC, JAC with 3m3 to 20m3 garbage compactor trucks.

III. Details of FOTON AUMAN 10m3 12m3 14m3 capacity Compressed Garbage Truck 10 Ton 12Ton Compactor Garbage Truck Factory Directly Selling

Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling

Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling

Load operation is less than 30 seconds, unloading operation time is less than 45 seconds;

Can choose 240L(single bin,double bins)or 360L,660L,1100L standard bin lifting and turnover mechanism,can also choose ground hopper and
other kinds of loading mechanism.

Automatic control-- The hydraulic control operation system can be controlled by electric and manual, one operation system button installed
in the cab, the other operation system button installed at the back of the upper body.

IV. Production workshop

There are more than 500 workers in our factory. Every production details are strictly controlled by our technicial engineers and production manager.

Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling

V. PRODUCT SHIPPING (RORO OR BULK SHIP OR CONTAINER)

RORO: The truck is driven to the ship inside directly and fixed well. It can protect the truck being rusty and broken during shipping.
BULK:  The truck is lifted by crane then put on the vessel deck. This model is much cheaper.
CONTAINER: The truck is put into the container. This model is used for small model trucks


Foton Auman 10m3 12m3 14m3 Capacity Compressed Garbage Truck 10 Ton 12ton Compactor Garbage Truck Factory Directly Selling

VI. COMPANY INFO

HUBEI FUYA VEHICLE CO.,LTD  is an authorized special truck manufacturer which has many years in design ,product ,sales
and service in special trucks like as
boom truck , fire truck, manlift truck, tank truck , garbage truck, tipper truck , wrecker truck ,
refrigerated truck, lpg and etc
. Main info as below:


Welcome to contact with us for more info. We will offer you the best truck as we can .
