High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line

Introducing the High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line. We are a factory specializing in high-quality beer packaging equipment.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
BGF
Filling Principle
Pressure
Packaging Container Lifting Structure
Chute Pneumatic Combination Lifting
Structure
Rotary
Packaging
Bottle
Packaging Material
Plastic
Material
SS304
Certificate
Ce,ISO,SGS
Composition
Filling Machine
Electrics
Siemens,Mitsubishi,etc
Bottle Volume
200ml-2000ml
Capacity
2000bph to 15000bph
Warranty
Two Years
Exchange Parts
Free
Shipping Term
by Sea
Main Function
Bottle Washing Filling Capping
Transport Package
Wooden Case
Specification
3.2m*1.8m*2.4m
Trademark
Proman
Origin
China
HS Code
8422301090
Production Capacity
150machines/Year Filling Machine

Product Description

High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line
Product Introduction This Series water washing filling capping 3-in-1 machine is mainly used for washing,filling sealing Non-Areated carbon dioxide drink such as mineral water,pure water,non-gas wine drink and so on.The machine design is shorten the time for the drink material contact with outside,increase the sanitation condition throught economy benefit.
High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line

Feature of Water Filling Machine:

1 Direct connection technology between air conveyor and in-feeding starwheel is applied to replace in-feeding screw and conveying chain to ease bottle changing process with only to change few parts. Newly-designed bottle-separating grippers are assembled to starwheel.
2 We adopts Neck-hanging technology in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only few parts need to be adjusted
3 Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4 High-speed, easily-cleaned filling valves with big flow volume are equipped with well CIP system and control system to rinse the equipment thoroughly.
5 splint of starwheel using twist descending way to simplify the process of bottle-size-changing. Only need to change arch board and starwheel, within ten minutes.

1)Water treatment system
Source water tank →Source water pump→ Quartz sand filter→ Active carbon filter→ Ion soften machine→ Fine filter →Reverse Osmosis → Ozone sterilizer → pure water tank
(Description: The processing flow adopted by a set of Pure Drinking Water Treatment System depends on quality of water source and target purpose of water usage. The selected flow basically includes three parts: pretreatment system, micro processing system and terminal processing system. The Pretreatment system includes multi-media filter, active carbon filter, softener, iron-manganese removal filter, ultra-filter, micro-filter, etc. The micro processing system adopts membrane filtration and ion exchange method. The terminal processing system involves in ozone/UV sterilization, iron exchange etc.)

2) Bottle filling & packing system
Pure water tank→Bottle blower→Air conveyor →Washing, filling & capping 3-in-1→ Light checkFull-automatic labeling machine Ink jet machine Full automatic PE film packing machine→ warehouse
(Description:
Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180~ along the conveying rail. There is once time of internal and external washing, the efficiency of bottle washing is high.

High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line


Capability Character
It adopts hanging type conveying-bottle structure to make changing bottle more convenient,faster and easier.Themain machine adopts advanced PLC control technology.The key electric elements adopt international famous products.
High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line

Technical Character
Model CGF8-8-3 CGF14-12-4 CGF18-18-6 CGF24-24-8 CGF32-32-10 CGF40-40-12
Number of rinsing head 8 14 18 24 32 40
Number of filling head 8 12 18 24 32 40
Number of capping head 3 4 6 8 10 12
(500m)Rated production capacity 1000-2000 2000-4000 6000-8000 8000-12000 12000-16000 16000-20000
(KW)Installed capacity 3 3.5 4 4.8 7.6 8.3
LxWxH(mm)Overall size 1900×1420×200 2200×1600×2300 2450×1900×2300 2750×2180×2400 4600×2300×2300 4550×265×2300


S.N. Name Remark
1 Washing head with bottle neck hanging Made by our factory
2 Filling valve Made by our factory
3 Sealing head Made by our factory
4 Touch screen Siemens
5 Transducer Delixi
6 PLC Siemens
7 Approach switch Autonics
8 Light fiber switc Autonics
9 Pneumatic elements Airtac


High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line

High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line

High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line

High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line
High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line
High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line
High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line
High-Tech Beer Glass Bottle Bottling and Sealing Machine/Production Line
