Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing

Get high precision UCFL series flanged bearing unit, pillow blocks, and agricultural machinery parts from our factory direct sales. HT200, HT160, HT150 bearing housing available.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Product Parameters
  • More Choices
  • Advantage Products
  • Company Profile
  • Packaging & Shipping
  • Our Advantages
  • FAQ
Overview

Basic Info.

Model NO.
UCFL208
Rows Number
Single
Raceway
Spherical Raceway
Material
Bearing Steel
Bearing Block Model
F
Compressive Strength
HT200/HT180
Seal
Flat Seal/Star Seal/Triple Seal/F Seal
Application
Agricultural Machinery etc.
Bearing Mode
HCP204-12/HPC215-48
Features
Low Noise/High Precision/Long Life
Cage Material 1
Cast lron / Brass / Bearing Steel
Cage Material 2
stainless Steel / Rubber / Plastic / Ceramic
Cage Material 3
PTEF / Alloy / Carbon Steel
Rolling Material
Steel Ball/Bearing Steel/Stainless Steel/Ceramic
Clearance
C0/C2/C3/C4
Noise&Vibration
Z1V1/Z2V2/Z3V3/Z4V4
Precision Level
P0/P6/P5/P4/P2
Delivery
Fast delivery, Some stocks
Transport Package
Pallet/Carton/Industrial Package / Color Box
Specification
standard/Customized
Trademark
TANN/NEUTRAL/OEM
Origin
Fujian, China
HS Code
8483200000
Production Capacity
75000000/Year

Packaging & Delivery

Package Size
20.00cm * 30.00cm * 40.00cm
Package Gross Weight
25.000kg

Product Description

Product Description

The TANN mounted bearing units is a bearing which combines the spherical outside surface ball bearing, seal, and a housing of high-grade cast iron or pressed steel. It features a variety of structure patterns, and is suitable for application under tough conditions.

Product Parameters
UCFL 2 TANN
Oval flange unit  Standard duty
Set screw type
Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing
Unit No. Dimensions (mm / inch) Bolt Size mm inch Bearing No. Housing No. Weight (kg)
d a e i g l S b z t B n
UCFL201 12 113 90 15 11 25.5 12 60 33.3 37.5 31 12.7 M10 UC201 FL203 0.45
UCFL201-8 1/2 4-7/16 3-35/64 19/32 7/16 1 15/32 2-3/8 1-5/16 1-31/64 1.2205 0.5 3/8 UC201-8 0.44
UCFL202 15 113 90 15 11 25.5 12 60 33.3 37.5 31 12.7 M10 UC202 FL203 0.44
UCFL202-9 9/16 4-7/16 3-35/64 19/32 7/16 1 12.46875 2-3/8 1-5/16 1-31/64 1.2205 0.5 3/8 UC202-9 0.44
UCFL202-10 5/8 UC202-10 0.44
UCFL203 17 113 90 15 11 25.5 12 60 33.3 37.5 31 12.7 M10 UC203 FL203 0.43
UCFL203-11 11/16 4-7/16 3-35/64 19/32 7/16 1 15/32 2-3/8 1-5/16 1-31/64 1.2205 0.5 3/8 UC203-11 0.42
UCFL204 20 113 90 15 11 25.5 12 60 33.3 37.5 31 12.7 M10 UC204 FL204 0.41
UCFL204-12 20.75 4-7/16 3-35/64 19/32 7/16 1 15/32 2-3/8 1-5/16 1-31/64 1 .2205 0.5 3/8 UC204-12 0.41
UCFL205 25 130 99 16 13 27 16 68 35.8 40 34.1 14.3 M14 UC205 FL205 0.58
UCFL205-13 13/16 5-1/8 3-57/64 5/8 1/2 1-1/16 5/8 2-11/16 1-13/32 1-9/16 1.3425 0.563 1/2 UC205-13 0.62
UCFL205-14 7/8 UC205-14 0.61
UCFL205-15 15/16 UC205-15 0.59
UCFL205-16 1 UC205-16 0.58
UCFL206 30 148 117 18 13 31 16 80 40.2 44.5 38.1 15.9 M14 UC206 FL206 0.86
UCFL206-17 1-1/16 5-13/16 4-39/64 45/64 1/2 1-7/32 5/8 3-5/32 1-19/32 1-3/4 1.5 0.626 1/2 UC206-17 0.89
UCFL206-18 1-1/8 UC206-18 0.88
UCFL206-19 1-3/16 UC206-19 0.86
UCFL206-20 1-1/4 UC206-20 0.85
UCFL207 35 161 130 19 14 34 16 90 44.4 48.5 42.9 17.5 M14 UC207 FL207 1.08
UCFL207-20 1-1/4 6-11/32 5-1/8 3/4 35/64 1-11/32 5/8 3-35/64 1-3/4 1-29/32 1.689 0.689 1/2 UC207-20 1.14
UCFL207-21 1-5/16 UC207-21 1.11
UCFL207-22 1-3/8 UC207-22 1.08
UCFL207-23 1-7/16 UC207-23 1.05
UCFL208 40 175 144 21 14 36 16 100 51.2 55.5 49.2 19 M14 UC208 FL208 1.44
UCFL208-24 1-1/2 6-7/8 5-43/64 53/64 35/64 1-13/32 5/8 3-15/16 2-1/64 2-3/16 1.937 0.748 1/2 UC208-24 1.48
UCFL208-25 1-9/16 UC208-25 1.45
UCFL209 45 188 148 22 15 38 19 108 52.2 56.5 49.2 19 M16 UC209 FL209 1.74
UCFL209-26 1-5/8 7-13/32 5-53/64 55/64 19/32 1-1/2 3/4 4-1/4 2-1/16 2-7/32 1.937 0.748 5/8 UC209-26 1.84
UCFL209-27 1-11/16 UC209-27 1.80
UCFL209-28 1-3/4 UC209-28 1.76
UCFL210 50 197 157 22 15 40 19 115 54.6 59.5 51.6 19 M16 UC210 FL210 2.10
UCFL210-29 1-13/16 7-3/4 6-3/16 55/64 19/32 1-37/64 3/4 4-17/32 2-5/32 2-11/32 2.0315 0.748 5/8 UC210-29 2.22
UCFL210-30 1-7/8 UC210-30 2.17
UCFL210-31 1-15/16 UC210-31 2.12
UCFL210-32 2 UC210-32 2.08
UCFL211 55 224 184 25 18 43 19 130 58.4 63 55.6 22.2 M16 UC211 FL211 2.91
UCFL211-32 2 8-13/16 7-1/4 63/64 23/32 1-11/16 3/4 5-1/8 2-5/16 2-15/32 2.189 0.874 5/8 UC211-32 3.06
UCFL211-33 2-1/16 UC211-33 3.00
UCFL211-34 2-1/8 UC211-34 2.95
UCFL211-35 2-3/16 UC211-35 2.89
UCFL212 60 250 202 29 18 48 23 140 68.7 73.5 65.1 25.4 M20 UC212 FL212 3.74
UCFL212-36 2-1/4 9-27/32 7-61/64 1-9/64 23/32 1-7/8 29/32 5-1/2 2-23/32 2-57/64 2.563 1 3/4 UC212-36 3.87
UCFL212-37 2-5/16 UC212-37 3.79
UCFL212-38 2-3/8 UC212-38 3.72
UCFL212-39 2-7/16 UC212-39 3.65
UCFL213 65 258 210 30 22 50 23 155 69.7 74.5 65.1 25.4 M20 UC213 FL213 4.57
UCFL213-40 2-1/2 10-5/32 8-17/64 1-3/16 7/8 1-31/32 29/32 6-3/32 2-3/4 2-15/16 2.563 1 3/4 UC213-40 4.66
UCFL213-41 2-9/16 UC213-41 4.57
UCFL214 70 265 216 31 22 54 23 160 75.4 - 74.6 30.2 M20 UC214 FL214 5.11
UCFL214-42 2-5/8 10-7/16 8-1/2 1-7/32 7/8 2-1/8 29/32 6-5/16 2-31/32 - 2.937 1.189 3/4 UC214-42 5.32
UCFL214-43 2-11/16 UC214-43 5.22
UCFL214-44 2-3/4 UC214-44 5.12
UCFL215 75 275 225 34 22 56 23 165 78.5 - 77.8 33.3 M20 UC215 FL215 5.37
UCFL215-45 2-13/16 10-13/16 8-55/64 1-11/32 7/8 2-7/32 29/32 6-1/2 3-3/32 - 3.063 1.311 3/4 UC215-45 5.62
UCFL215-46 2-7/8 UC215-46 5.51
UCFL215-47 2-15/16 UC215-47 5.40
UCFL215-48 3 UC215-48 5.28
UCFL216 80 290 233 34 22 58 25 180 83.3 - 82.6 33.3 M22 UC216 FL216 7.20
UCFL216-49 3-1/16 11-13/32 9-11/64 1-11/32 22.875 2-9/32 63/64 7-3/32 3-9/32 - 3.252 1.311 7/8 UC216-49 7.38
UCFL216-50 3-1/8 UC216-50 7.25
UCFL216-51 3-1/16 UC216-51 7.12
UCFL217 85 305 248 36 24 63 25 190 87.6 - 85.7 34.1 M22 UC217 FL217 8.61
UCFL217-52 3-1/4 12 9-49/64 1-27/64 15/16 2-15/32 63/64 7-15/32 3-7/16 - 3.374 1.343 7/8 UC217-52 8.83
UCFL217-53 3-5/16 UC217-53 8.69
UCFL217-55 3-7/16 UC217-55 8.40
UCFL218 90 320 265 40 24 68 25 205 96.3 - 96 39.7 M22 UC218 FL218 10.51
UCFL218-56 3-1/2 12-19/32 10-7/16 1-37/64 15/16 2-11/16 63/64 39463 3-25/32 - 3.7795 1.563 7/8 UC218-56 10.62

More Choices

Our main product ranges are ball bearings and full ranges of mounted bearing units, including 60 series, 62series, 63 series; thin-wall bearing such as 68 series and 69 series, and also flange bearings, inch bearings, high precision angular contact bearing; UC/UCP/UCF/UCFL/UCT, etc. Non-standard bearings based on customer's demand are available too.

Wide range of products from strong supplying supplying chains to make suitable solution.

Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing

Advantage Products





Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing
Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing
Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing
Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing
Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing
Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing




Features

Rational self- alignment
Larger load carrying capacity, relubrucable, longer service life of the units
Efficient, sealing ability of the units with covers is perfect
Solid housing, provide max rigidty against deformation for any condition
Easy and positive locking to shaft
Special heat-treatment on bearing inner ring prevent causing cracking
Unique device to prevent bearing outer ring rotation
Complete interchangeability between bearing and housing
Easy installlation
Easy positioning for mounting

Application

Agriculture Mining
Engineering Chemical machinery
Textile Plastic
Dyeing and fining Other industries
Company Profile

About Us

Focus on a variety of industries
Provide maintenance solutions
Optimize customer inventory and reduce cost

Established in 2012, Xiamen Granville is a branch of the Granville Group. With our experience, competitive prices and excellent service, we have won the praise of our customers. Our business involves standard and special industrial parts, automotive parts and construction machinery parts required for a variety of different industrial applications.
Our main products include
Bearing series :
ball bearings, deep groove ball bearings, self-aligning ball bearings, angularcontact ball bearings, cylindrical roller bearing, tapered roller bearings, thrust ball bearings, thrust rollerbearings, needle bearings, spherical bearings, joint bearings, pillow blocks, linear bearings, etc.
Accessories series:Automotive Spare Parts,Seals & O-rings ,Power transmission parts Chain and Sprocket
Our products are mainly exported to Europe, America, Middle East, Southeast Asia, India, Pakistan, Bangladesh, Singapore, Korea and other countries around the world. We have a large number of products in stock, which can be delivered with high efficiency in the shortest possible time to solve your matching problems in time. In addition, we have reliable quality and quantity of products to offer. We adhere to the principle of win-win situation and insist on "providing comprehensive quality products and best reputation" to provide excellent services to our customers.
Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing

What We Do

Comprehensive product range:
- Bearings
- Oil seals, Transmission belt
- Chain and Sprocket
- Hub assembly & Wheel bearings
- Coupling, castings
Linear motion

Packaging & Shipping



Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing
Manufacturer direct sales High Precision UCFL series Flanged bearing unit/ Pillow Blocks/Agricultural Machinery parts/HT200/HT160/HT150 Bearing Housing
Our Advantages

1. We have the most advanced bearing process equipment, CNC automatic facilities, and testing instruments.
2. We manufacture ball bearings and mounted bearing units, and also provide a strong full range of products, including electric motors and components One-stop partnerships products from our audited supply chain.
3. All products are manufactured exclusively by companies with ISO 9001:2008 certified Quality Systems which use state-of-the-art machines. The quality path starts from the beginning to deliver and goods' quality trackable

Our Values
Behavior-based, service-oriented, focused on results and committed to continuous improvement

Advantage Manufacturing Processes and Quality Control:

01Heat Treatment
02 Centerless Grinding Machine 11200 (most advanced)
03 Automatic Production Lines for Raceway
04 Automatic Production Lines for Raceway
05 Ultrasonic Cleaning of Rings
06 Automatic Assembly
07 Ultrasonic Cleaning of Bearings
08 Automatic Greasing, Seals Pressing
09Measurement of Bearing Vibration (Acceleration)
10 Measurement of Bearing Vibration (Speed)
11 Laser Marking
12 Automatic Packing



After Sales Service

  1. Optimize customer inventory and reduce cost
  2. Provide maintenance solutions



Quality Warranty

Granville as a manufacturer of high quality products, guarantees compliance with the highest standards relative to the use of the best steel quality in the production process, the highest standards in the design of contact surfaces, as well as the most efficient packing and lubrication of parts. From material coming, quality control through all processes. Except interal test, goods to third party inspection if required. After the center of inspection and experiment being founded, effective methods of inspecting all kinds of raw materials are mastered and then the reliability of bearings is ensured. One of our main objectives is the continued improvement in the quality of our products and processes, in pursuit of which we obtained ISO certification 9001:2008 and TS16949.

FAQ

Q1.Can you accept OEM and customization?

A: Yes. We can customize it according to the samples and drawings you provide.

Q2. Do you keep a stock of these things ?
A: In stocks

Q3.Can you provide samples free of charge?
A: Yes. We can provide samples free of charge. But the freight is paid by the customer.

Q4.What's the delivery date?
A: The delivery time of sample orders is 3 working days.The bulk orders are 5-10 working days.

Q5: Why your price is higher than others?
A: Price = quality . We firmly believe that by the quality of the customer is always get more reliable than on price . So we insist on doing high-quality products.

Q6:What kind of transport do you have ?
A: According to the weight,we will choose the most appropriate mode of transport for you. Our freight forwarding is efficient and cheap
