Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring

Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring - Manufactured at our factory for high-quality and durable performance.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Boyuan Casting
Surface Roughness
Ra3.2
Machining Tolerance
+/-0.01mm
Standard
ASME
Certification
CE, ISO 9001:2015
Item
Nozzle Ring
Raw Material
Inconel 713/718
Technics
Lost Wax Casting
Surface Treatment
Sand Blasting and Polishing
Machining Service
Yes
Service
OEM and Customized
Package
Carton Box, Plywood Cases
Sample
1 or 2 Pieces
Size
as Per Customer′s Requirements
Usage
Turbojet Engine, Engine Turbocharger
Transport Package
Plywood Case
Specification
OEM and Customized
Trademark
BOYUAN
Origin
Weifang
HS Code
8412901090
Production Capacity
50000PCS/Year

Product Description

Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring


Superalloy nozzle ring/nozzle guide vane used for Turbojet Engine, Locomotive and Marine turbocharger, turbo nozzle ring is finished by integral casting. And casting method of noizzle ring is lost wax investment & vacuum casting, casting surface smoothness can meet Ra3.2μm, production process of nozzle ring is Silica sol process.

The blade thickness can be 0.5mm.


The material of nozzle ring/nozzle guide vane can be Inconel738LC, Inconel713c, Inconel618... Please see the material chemical composition of IN718 for reference:

Element C Cr Co Mo Ni Fe Mn Si S Cu
Content ≤0.08 17.0-21.0 ≤1.0 2.8-3.3 50-55 BAL ≤0.35 ≤0.35 ≤0.015 ≤0.30
Element Al Ti
Content 0.2-0.8 0.65-1.15

Detailed Photo

Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring
Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring
Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring




About casting production equipments we have:
    * Aluminum low pressure casting furnace
    * Vacuum casting furnace
    * Injection wax machine
    * Shell drying line
    * Constant temperature and humidity room
    * Plaster shell chamber
    * Sandblasting machine
    * Heat treatment furnace



Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring
Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring



About machining production equipments we have:
    * DMG five axis machining center
    * Three axis machining center
    * Doosan CNC center Lathe
    * General CNC Lathe
    * Dynamic balancing machine
    * Overspeed testing machine
    * Radial Drilling machine



Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring
Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring
Nickel Base Alloy Silica Sol Casting Steam Turbine NGV Nozzle Ring



Our raw material:
1. Nickel base alloy (Inconel738LC,Inconel713c,Inconel618,HastelloyS,HastelloyX,Inconel703,Inconel600,ect,…)

2. Iron base alloy (K213/HU/HW…)

3. Cobalt base alloy

4. Tungsten base alloy

5. Stainless steel (201,202,301,303,304,304H,304L,305,309S,316,316Ti,317,317L,316N ect,…)

6. Aluminum alloy (C355/ZL102/A380A…)


Capacity Instruction:

1.Sample precision field surveying and mapping, Complete custom processing.

2.According to the graphic drawing,realize 3d modeling, customized production.

3.The company built workshop 20000 m2, we have several professional engineer and inspector, production lines working at the same time, promise the products delivery on time

4.When production, we finish different testing include: Raw material inspection, first products inspection, process inspection and final inspection, we make sure our customer receive qualified products.


Warranty
N/A
Customized support
OEM, ODM
Place of Origin
China

Shandong
Model Number
Customized
Brand Name
OEM/ODM
Product name
Nozzle Ring
Material
Inconel Alloy
Size
Customer's Drawing Required
Feature
High Precision
Service
OEM\ODM
Port Size
Standard/Customized
Packing
Carton/Wooden Cases
Surface Treatment
Coating



Our Advantages:

1>Fully automatic the free cylinder pressure wax machine

2>Water blasting machine for surface treatment of high standards

3>Constant temperature and humidity system shell pipeline

4>Efficient vacuum melting and casting furnace

5>Automatic large heat treatment furnace

6>Aluminum alloy low pressure casting machine

7>Hot steam dewaxing autoclave

8>high degree of automation equipment

9>Almost 20 years of manufacture & customer service experience

10>OEM service offer



Quality Control

We have full set of quality control system to guarantee best product quality. Depends on the products, we make different item testing plan, different manufacturing procedure and provide certified lab mechanical testing.
