Basic Info.
Model NO.
S00013412
Engine Speed
1500rpm/1800rpm
Frequency
50Hz/60Hz
Aspiration Engine Typ
Turbocharged
Cooling System
Water Cooled
Governing Type
Electrical Starting GAC
Delivery
by Shipping or by Airway
Part Type
Brand New
Quality Standard
ISO9001, ISO14001, CE
Transport Package
Plastic Seaworth Packing with Carton
Specification
250*220*210mm; 18.0kg
Trademark
SDEC
Origin
China
HS Code
8414803090
Production Capacity
10000
Product Description
Part name: Turbocharger
Part number: S00013412 (WF70)
For SDEC Shangchai G Series engine model: SC13G420D2, etc.
ΔFAQ
1.What's your power range of Generators?
Answer: We can offer the range from 5kva~3000kva.
2.What's your delivery time?
Answer: Generally,we can delivery in 15-35 days after confirmation of order.
3.What's your payment?
Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment
or L/C at sight. But based on some special project and special order,we can do something support on payment item.
4.What's your warranty?
One year or 1000 hours (according to whichever reach first) from Ex-Factory date
5.What's your MOQ?
Answer:We accept power generator MOQ is 1 set .
WINTPOWER Service System
Customer-focused traditional service better and better service levels worldwide-network Service
Concepts:Ensure that customers at ease using for WINTPOWER Products Serving the customers, WINTPOWER gains trust .Work together with Customers During the service period, WINTPOWER do best firstly and protects customers' interests.
In case of failure to use the generator, WINTPOWER help customer until they know how to use
WINTPOWER Service Principles
Customer foremost and honesty as foundation. Serving the customers heart and soul at all levels 24 hours each day.
Δ Factory Inspection: the test items before delivery are mainly as follows:
1.Each gensets shall be put into commission and loading more than 1 hours totally. They are tested on idle
load, testing range 25% 50% 75% 100% 110% 75% 50% 25% 0%
2.The noise level is tested by requested
3.All of the meters on the control panel shall be tested
The appearance of the genset and all of the label and nameplate shall be checked
Part number: S00013412 (WF70)
For SDEC Shangchai G Series engine model: SC13G420D2, etc.
| SC15G500D2 SDEC Shanghai Engine Spare Parts Maintenance List Repair Overhaul | |||
| 500Hours Maintenance Spare Parts List | |||
| Item | Description | Part Number | Qty |
| 1 | CARTRIDGE,LUB | D17-002-02 | 2 |
| 2 | FILTER,FUEL | S00010128 | 1 |
| 3 | CLEANER,AIR | KW3040-200/KW3040-300 | 1 |
| 1000Hours Maintenance Spare Parts List | |||
| Item | Description | Part Number | Qty |
| 1 | CARTRIDGE,LUB | D17-002-02 | 2 |
| 2 | FILTER,FUEL | S00010128 | 1 |
| 3 | CLEANER,AIR | KW3040-200/KW3040-300 | 1 |
| 4 | Front Crankshaft Seal | G02-119-02 | 1 |
| 5 | Rear Crankshaft Seal | S00015078 | 1 |
| 6 | BEARING,CRANKSHAFT THRUS | G02-114-01 | 4 |
| 7 | BEARING,MAIN | G02-112-01 | 7 |
| 8 | BEARING,MAIN | G02-113-01 | 7 |
| 9 | BEARING,CONNECTING ROD(UP) | G05-112-01 | 6 |
| 10 | BEARING,CONNECTING ROD (LOW) | G05-112-01 | 6 |
| 11 | PISTON RING | S00009738 | 6 |
| 12 | PISTON RING | G05-108-03 | 6 |
| 13 | OIL RING | G05-002-03 | 6 |
| 14 | FAN BELT | S00011689 | 1 |
| 15 | GASKET,VALVE COVER | 761G-04-074A | 3 |
| 16 | FUEL INJECTOR | S00011108 | 6 |
| 3000Hours Maintenance Spare Parts List | |||
| Item | Description | Part Number | Qty |
| 1 | CARTRIDGE,LUB | D17-002-02 | 2 |
| 2 | FILTER,FUEL | S00010128 | 1 |
| 3 | CLEANER,AIR | KW3040-200/KW3040-300(S00016428) | 1 |
| 4 | BEARING,CRANKSHAFT THRUS (up) | G02-114-01 | 4 |
| 5 | BEARING,MAIN | G02-112-01 | 7 |
| 6 | BEARING,MAIN | G02-113-01 | 7 |
| 7 | BEARING,CONNECTING ROD(UP) | G05-112-01 | 6 |
| 8 | BEARING,CONNECTING ROD (LOW) | G05-112-01 | 6 |
| 9 | PISTON RING | S00009738 | 6 |
| 10 | PISTON RING | G05-108-03 | 6 |
| 11 | OIL RING | G05-002-03 | 6 |
| 12 | TAPPET | G04-101-01 | 12 |
| 13 | CAMSHAFT BUSHING | G02-115-01 | 7 |
| 14 | CAMSHAFT | G09-101-03 | 1 |
| 15 | ROD,ENGINE CONNECTING | S00010687 | 6 |
| 16 | THERMOSTAT | S00010360 | 1 |
| 17 | PUMP,LUBRICATION OIL | S00005249 | 1 |
| 18 | PUMP,WATER | S00010129 | 1 |
| 20 | ROD,PUSH | G04-102-02 | 12 |
| 21 | LINER,CYLINDER | G02-102-01 | 6 |
| 22 | PISTON,ENGINE | G05-101-09 | 6 |
| 23 | PIN,PISTON | A761-05-004 | 6 |
| 24 | RING,RETAINING | B00001041 | 12 |
| 25 | ORIFICE, PISTON COOLING JET | S00006214 | 6 |
| 26 | VALVE,INTAKE | A761Z-04-004 | 6 |
| 27 | VALVE,EXHAUST | G04-104-02 | 6 |
| 28 | SENSOR,SPEED | S00011439 | 1 |
| 29 | FAN BELT | S00011689 | 1 |
| 30 | GASKET,VALVE COVER | 761G-04-074A | 3 |
| 31 | GASKET,OIL COOLER CORE | S00012519 | 4 |
| 32 | WASHER,SEALING | S00009442 | 1 |
| 33 | GASKET,CYLINDER HEAD | S00011414 | 1 |
| 34 | TURBOCHARGER | S00013412 | 1 |
| 35 | GASKET INJECTOR | S00006088 | 6 |
| 36 | MOTOR,STARTING | S00011506 | 1 |
| 37 | ALTERNATOR | S00011521 | 1 |
| 38 | FUEL INJECTOR | S00011108 | 6 |
| 39 | PUMP,FUEL INJECTOR | S00010119 | 1 |
| 40 | CORE,COOLER | S00010821 | 2 |
